35,000 sq. ft. trimix floored factory area in two-bay and machine shop 2 NOS of ten TON, 2 NOS 15 TON. 2 NOS of 5 TON EOT cranes 10-meter-high ceiling
Sepearate Fabrication for SS and MS:
TOTAL PLOT AREA SQFT 88,000
CONSTRUCTED AREA SQFT 35,000
FABRICATION SHOP - SS AND NON-FERROUS 172 FETT X 72 FEET X 30 FEET HT
FABRICATION SHOP - FERROUS 172 FETT X 72 FEET X 30 FEET HT
MACHINE SHOP 35 FETT X 115 FEET X 30 FEET HT
ENGINEERING STORE, 800 SQFT
ADMINISTRATIVE, CONFERENCE, DESIGN 1500 SQFT
ELECTRIC POWER 200 KW TRANSFORMER
UNDERGROUND WATER TANK 25000 LTR 60000 Ltr Vertical MS st Tank
FIRE FIGHTING SYSTEMS 32. 5 HP
Plant and Machinery:
EOT Crane: capacity 10 ton – 02 nos, 15 ton – 02 nos, 5 ton – 02 nos.
Plate Bending M/C: 02 nos – 2500 width and 20 mm thk
Centre Lathe: 8 feet – 01, 10 feet – 01, 18 feet – 02
Plasma Cutting M/C: - 02 nos – 25 mm thk
Milling M/c: 01 no
Portable Keyway Machine: 01 no
Radial Drill M/c and Pedustal Drill M/c: 40 mm drill – 02 nos
Welding Rectifier:
Motorized Hydro test Pump:
Quality check records
Quality Assurance Plan
WPS / PQR / WPQ
Material Identification Chart/ Heat Chart
Radiography / U.T. / M.P.T. Verification Report
Final Dimension Report
Material Heat Chart with Test Certificate
Hydro / Pneumatic Test Report/ Agitator running Trial Report.
Rub Off
As Built Drawing
Fabrication codes:
Over our 35 years of experience, we have manufactured as per various codes of construction and complied with numerous standards. Some of them are:
ASME Sec. 8 Div 1
ASME Sec. 8 Div 2
PED
API 650
TEMA R/ C/ B
IS 2825 & related IS Codes.
Welding & Brazing Qualification – ASME sec. IX
Nondestructive Examination – ASME sec. V
Ferrous Material Specification – ASME sec. II part (A)
Non-Ferrous Material Specification – ASME sec. II par (B)
Material Specification for welding rod Electrode & Filler Wire. – ASME sec. II part (C)
Material Properties – ASME sec. II part (D)
Manufacturing equipment under various tpi agencies:
M/ s. Bureau Veritas (India) Pvt. Ltd.
M/s. Det Norske Veritas
M/s. SGS Inspection
M/s. American Bureau of Shipping
M/s. Lloyd’s India Inspection
M/s. IR CLASS Systems & Solutions Pvt. Ltd.
M/s. Chempro Inspections Pvt. Ltd.
M/s. TUV Nord India
